Table columns Meaning Functions
Time offset The time offset (also known as
the GAP time), is the time be‐
tween the end and the start of
two chained batches.
Click a cell in the "Time offset" col‐
umn with the mouse for a chained
batch and enter the required time
offset in seconds. The successor
batch does not start until the time
offset you specified is reached.
Start time Displays the original planned
start time for batches. The start
time is specified when the
batch is created.
None.
End time Displays the end time originally
calculated. The end time is de‐
termined by the master recipe
used; it is calculated by the sys‐
tem.
None
11.4.8 Display of parameter interconnections
Display of interconnected parameters
Interconnected parameters (cross-interconnections and target interconnections) are displayed
and edited on the "Parameters" tab in the OS Properties control.
Symbol in the "Name"
table column
Meaning
Part of a cross-interconnection.
Part of a target interconnection.
Part of a cross-interconnection and target interconnection.
Each parameter row shown in which one of the three symbols above is displayed contains
command(s) to navigate to the corresponding parameter (source/target) in the shortcut menu.
For example, if you select the batch folder in the navigation area and have also selected the
"Parameters" tab, you will see all interconnected parameters of the control recipe of the batch
at a glance. In the shortcut menu, the symbols indicate which direction you can navigate in the
recipe hierarchy.
Additional information
Parameter interconnections (Page 561)
BATCH OS controls
11.4 Applications in process mode
SIMATIC BATCH V8.2
632 Operating Manual, 02/2016, A5E35958174-AA
