"Help" button
Opens the SIMATIC BATCH online help for this context.
14.1.12.39 "EPH" selection
EPH equipment phase selection
You have selected the "EPH equipment phase" object in the "Process cell data" list.
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description The description of the equipment module is displayed in this text box. You
enter description texts in the object properties in SIMATIC Manager.
Runtime name: Corresponds to the WinCC variable name plus the OS name as prefix.
CFC chart CFC chart name in which the block is placed.
Assigned phase type: Type definition for process cell-neutral recipe creation.
"Type" button Activating this button takes you to the corresponding phase type. With the
"Back" button of the phase type, you return to beginning selection.
Control strategies: If the assigned phase type was defined as a control strategy type, you can
exclude certain control strategies from the control strategies defined for the
type using the "Change" button. The control strategies excluded in this
manner will no longer be available for this instance in batch control. For
SFC types this is not possible because the control strategies are defined
in the block. If a control strategy is not defined the line will not be displayed.
"Change" button Use the "Change" button to exclude certain control strategies from all the
control strategies defined on the type.
"Open" button not possi‐
ble in the multiproject.
Click on the "Open" button to open the appropriate CFC chart and select
the block.
Block
No function.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
918 Operating Manual, 02/2016, A5E35958174-AA
