Properties
Name of the object selected in the process cell tree.
Description A description of the equipment module is displayed in this text box. You can enter a
descriptive text into the object properties of the neutral folder in the SIMATIC Man‐
ager.
Neutral folders
No special functions are available after selecting the "Neutral folder" object in the process cell
tree.
Note
Neutral folders are used only to group units or equipment modules so that the arrangement in
the process cell tree is clearer. CFC charts with BATCH modules, which are located directly
in a neutral folder are not taken into consideration by BATCH Engineering.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The "Display" button activates the log. The selected log is generated
as an XML file with the specified layout and displayed in the Internet
Explorer.
The "Display" button always shows all errors/warnings for the selected
"Process cell". Moreover, on a selected object you can right-click to
select the "Display Log" dialog to also show object-specific errors or
warnings.
Additional functions
The batch instances configured in the selected folder are displayed via the "Display" button.
"OK" button
Saves your settings and closes the dialog.
"Apply" button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
"Cancel" button
Closes the dialog without saving changes.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 917
