7.3.18.7 Executable functions in a removed project
Functions in the removed project with editable batch types
Function Selected object Description
Generate
● Batch types ● SFC types: Operation/phase types are generated from SFC
types with EOP/EPH IDs.
● BATCH interface blocks: Batch types (units of measure,
operation/phase types, process tag types) are generated from
the instances of the BATCH interface blocks.
● This command generates the batch types from the SFC types
or BATCH interface blocks of the project removed for editing.
Note: If Batch instances, SFC types or TAGCOLLECT FBs are
modified, the "Generate" function must be run prior to compilation.
The same applies to modifications in the PH, for example after
moving or copying CFC charts.
New
● Phase types
● Operation types
● Process tag types
Creation of phase, operation, and process tag types under the
selected area and creation of the corresponding type parameters.
Delete
● Data type
● User data type (if present)
● Units of measure
● Phase types
● Operation types
● Process tag types
● Equipment properties
You can delete data types, user data types, units of measure and
equipment properties in the selected folder. All non-instanced ob‐
jects are deleted. However, they remain available in the shared
declarations and will appear again during the next generation.
With operation types, phase types and process tag types, you can
select individual objects and delete them as long as they have not
been instanced.
Edit
● Phase types
● Operation types
● Process tag types
Editing the attributes of the batch types and type parameters.
Exception: SFC types
You will find a description of editing SFC types in the section
"Creating a new SFC type (Page 155)".
Additional
functions
Print
Batch types Printing:
Print all batch types of the process cell in tabular form.
Additional
function
● Display
● User data type (if present)
● Units of measure
● Phase types
● Operation types
● Process tag types
● Equipment properties
List of all instances that refer to this type object. Certain attributes
can be selected using a filter.
Log Batch types Display of the logs for the executed functions "Generate"
First select the executed function in the drop-down list and then
click the "Display" button.
Engineering
7.3 BATCH engineering
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 219
