Default: Yes.
The attribute can be dynamized with the ColumnFilterVisible name.
11.5.5.6 ToolbarOrderAndVisibility
String.
The attribute specifies the sequence of the toolbar symbols in the toolbar. If individual values
are not specified, the corresponding toolbar symbols are not displayed in the toolbar. The
settings made here also influence the shortcut menu. The table below lists the elements with
their symbols and values:
Toolbar elements Symbol Value
Dock/undock 1
Update 2
Display properties 3
Cancel 4
Delete 5
The values are separated by a semicolon and entered in the following syntax: 1;;3;4;;5;2.
Changing the sequence of the toolbar elements would, for example, produce the following
values: 2;;1;3;4;5. A double semicolon or the value 0 create a vertical line separator in the
toolbar. This allows you to group the toolbar symbols individually in the toolbar.
Default: 1;;3;4;;5;;2
The attribute can be dynamized with the ToolbarOrderAndVisibility name.
11.5.5.7 ToolbarVisible
Boolean variable.
This attribute specifies whether or not the toolbar is displayed in the control.
Default: Yes, the toolbar is used and displayed.
The attribute can be dynamized with the ToolbarVisible name.
11.5.6 SIMATIC BATCH OS Process Cell
11.5.6.1 CommunicationChannel
String.
Defines the communication channel for the selected BATCH project. Select the same
communication channel that you use in the "SIMATIC BATCH OS Master" control. This
ensures that you obtain the data for the unit allocation from the relevant BATCH project.
Default value = 1.
The attribute can be dynamized with the name CommunicationChannel.
BATCH OS controls
11.5 Control properties references
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 667
