Screen tips
To display a brief text explaining the buttons in the toolbar, position the cursor on a button until
the screen tip is displayed.
Changing the font size
With the menu command Options > Font in the help topic window, you can set the font size to
"small", "normal" or "large.
Note
If you start the Batch Control Center or BATCH Recipe Editor from a WinCC screen in process
mode, due to reasons of security no online help is available.
9.1.4 User interface and operation
9.1.4.1 Layout of the main window (BatchCC)
The basic layout of the user interface of BatchCC consists of individual windows and is shown
in the figure below. In the left section, the batch process cell or the BATCH project output is
shown with its objects in a tree structure. The main window shows the BATCH objects, for
example, in list form. You can control the view or windows with the "View" menu. There you
will find commands for displaying and hiding additional windows.
BATCH Control Center
9.1 Starting and operating
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 247
