Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display box The number of warnings for the selected log is displayed.
"Display" button The logging function is enabled with the "Display" button. The selected
log is generated as an XML file with the specified layout and displayed
in the Internet Explorer.
If "Process cell" is selected and you click the "Display" button, all errors
or warnings of the process cell are displayed. You can also right-click
on a selected object and select the "Display log" function to display
object-specific errors or warnings.
Additional functions
Display of possible additional functions.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.34 "Equipment properties parameters (type)" selection
Equipment property parameters selection
In the list "Process cell data" you have selected the object "Equipment properties parameter".
You can only change and use the properties and functions of the selected object with versions
5 and 6i.
All the information displayed in this dialog originate from the shared declarations you have
configured in the SIMATIC Manager.
Run time name in the dialog header
Display of the run time name.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
910 Operating Manual, 02/2016, A5E35958174-AA
