Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Description You can display or enter the description of the equipment properties pa‐
rameter in this text box.
Allocated data type This displays the assigned data type. Required user data types must be
declared under global declarations and must be made available to SIMATIC
BATCH through the "Generate" button.
Assigned "unit of meas‐
ure"
This displays the assigned unit of measure. You must declare required units
of measure under the shared declarations and make them available by
using the "Generate" function in SIMATIC BATCH.
"Data type" button Activating this button takes you to the appropriate data type. Use the Back
button on the data type to return to the initial selection point.
Parameter
No function.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The "Display" button activates the log. The selected log is generated
as an XML file with the specified layout and displayed in the Internet
Explorer.
The "Display" button is always shows all errors/warnings for the selec‐
ted "Process cell". Moreover on a selected object you can right click
to select the "Display Log" dialog to also show object-specific errors
or warnings.
Additional functions
Instances: Displays.
All the instance parameters that refer to this type parameter are listed in a dialog box. Certain
attributes can be selected using a filter.
OK button
Saves your settings and ends the dialog.
Apply button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 911
