Toolbar elements Symbol Symbol menu Value
Reset step 23
Complete step 24
Set/Remove breakpoint 34
Acknowledge breakpoint 35
Hide parameter 28
Update 26
SFC visualization: Overview 32
SFC visualization: Pane 33
Open with BCC 29
Close 27
View -
Overview 40 / -40
Right 41 / -41
Left 42 / -42
Top 43 / -43
Bottom 44 / -44
Above 45 / -45
Below 46 / -46
Use a negative or a positive value to specify whether or not the function "Undock automatically"
should be used by default. Example: If you enter the value -30 instead of the specified value
30 in the attribute for the "Undock automatically" function, the button is displayed in the OS
control as pressed, that is, the OS Control is automatically shown as undocked.
Default:
1;30;;36;37;38;39;;31;2;;3;4;5;6;;7;8;9;10;11;12;13;;14;15;25;;16;17;18;19;20;21;22;23;24;;3
4;35;;28;26;;32;33;29;;27
The attribute can be dynamized with the ToolbarOrderAndVisibility name.
11.5.3.8 ToolbarVisible
Boolean variable.
This attribute specifies whether or not the toolbar is displayed in the control.
Default: Yes, the toolbar is used and displayed.
The attribute can be dynamized with the ToolbarVisible name.
11.5.3.9 ParametersListColumnOrderAndVisibility
String.
BATCH OS controls
11.5 Control properties references
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 653
