Siemens SIMATIC BATCH User Manual

Properties
Name of the object selected in the process cell tree.
Description The description of the equipment operation is displayed in this text box.
You enter description texts in the object properties in SIMATIC Manager.
Process cell component
grouping
Runtime name: Corresponds to the WinCC variable name plus the OS
name as prefix.
CFC chart CFC chart name in which the block is placed.
"Open" button
Not possible in the multi‐
project.
Click on the "Open" button to open the appropriate CFC chart and select
the block.
Assigned operation type Type definition for process cell-neutral recipe creation.
"Type" button Activating this button takes you to the corresponding operation type. With
the "Back" button of the operation type, you return to beginning selection.
Control strategies If the assigned operation type was defined as a control strategy type, you
can exclude certain control strategies from the control strategies defined
for the type using the "Change" button. The control strategies excluded in
this manner will no longer be available for this instance in batch control. For
SFC types this is not possible because the control strategies are defined
in the block. If a control strategy is not defined the line will not be displayed.
"Change" button Use the "Change" button to exclude certain control strategies from all the
control strategies defined on the type
Batch process cell
Buttons
Compile
This button only exists for
a project and not for a
multiproject.
All batch instance blocks of the CFC chart of the selected object are read
in. This also implicitly involves a check for consistency with the batch types
and conformity to ISA-88.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Display of possible additional functions.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
922 Operating Manual, 02/2016, A5E35958174-AA
