Phase type
Buttons
New if you click the "New" button, a new phase type parameter of the selected
version is added.
When a phase type parameter is created, the version of the type can no
longer be changed.
Delete Click the "Delete" button to delete the selected phase type.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display box The number of warnings for the selected log is displayed.
"Display" button The logging function is enabled with the "Display" button. The selected
log is generated as an XML file with the specified layout and displayed
in the Internet Explorer.
If "Process cell" is selected and you click the "Display" button, all errors
or warnings of the process cell are displayed. You can also right-click
on a selected object and select the "Display log" function to display
object-specific errors or warnings.
Additional functions
Instances
"Display" button All instances that refer to this phase type are listed in a dialog.
Or no instance exists.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 887
