Properties
Name of the object selected in the process cell tree.
Description The description of the data type parameter is displayed in this text field.
Enter the description text within the Global declarations > Enumerations >
Enumeration type > Value, in the object properties in the Comment field in
the SIMATIC Manager.
Label Enter the label within the Global declarations > Enumerations > Enumera‐
tion type > Value, in the object properties in the Value field in the SIMATIC
Manager.
Value
No functionality available.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file in the specified layout and shown
in Internet Explorer.
Select "Process cell" and click on the "Display" button to show all proc‐
ess cell errors or warnings. Moreover on a selected object you can
right click to select the "Display Log" dialog to also show object-specific
errors or warnings.
Additional functions
None.
"OK" button
Saves your settings and ends the dialog.
Accept button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
"Cancel" button
Closes the dialog without saving changes.
"Help" button
Opens the SIMATIC BATCH online help for this context.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
876 Operating Manual, 02/2016, A5E35958174-AA
