Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Data types
Button
Delete Click on the "Delete" button to open the "Delete data types" dialog. Click
"Yes" to delete all unused user data types in SIMATIC BATCH. When you
use the "Generate" function in the BATCH configuration dialog, the data
types are loaded again from the ES.
This function is practical when you have declared user data types that are
not relevant for SIMATIC BATCH.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file in the specified layout and shown
in Internet Explorer.
Select "Process Cell" and click on the "Display" button to show all
process cell errors or warnings. Moreover on a selected object you can
right click to select the "Display Log" dialog to also show object-specific
errors or warnings.
Additional functions
Display of possible additional functions.
"OK" button
Saves your settings and ends the dialog.
Accept button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
"Cancel" button
Closes the dialog without saving changes.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 873
