Properties
Name of the object selected in the process cell tree.
Description You describe your batch types in this text box.
Last changed on The most recent change of the batch types is specified with date and time.
Batch types
Button
Generate With this button, you start to generate or read in the batch types. All SFC
types (EPH, EOP) and all BATCH interface blocks in the CFC charts from
which the types are generated are read in.
Log
Drop-down list box Logging for the generation is offered.
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Print: This prints all batch types of the process cell in tabular form.
Note
Editing, creating and deleting batch types is possible only in a project of multiproject or in a
multiproject but not in a standalone project.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
934 Operating Manual, 02/2016, A5E35958174-AA
