Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Operation types, phase types, and process tag types
– Equipment properties → currently selected element
By selecting the "Equipment properties" folder, you can create new equipment
properties; by selecting a created equipment property, you can change its properties.
● Batch instances:
– Process cell (folder)
– Units (folder)
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Created by Specification of the application that created the object, either SIMATIC
BATCH PCell Control Center or SIMATIC Manager.
● If a type object was created by SIMATIC Manager, additional subobjects
cannot be added, nor can the selected object be deleted or changed,
either via the PCC API or with the PCC configuration dialog.
● If an instance object was created by SIMATIC Manager, additional
subobjects can be added via the PCC API or with the PCC configuration
dialog. However, it is still not possible to delete or change the selected
object here.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
1004 Operating Manual, 02/2016, A5E35958174-AA
