Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Phase types
– Operation types
– Process tag types
– Equipment properties
● Batch instances
– Process cell (folder)
– Units (folder) → currently selected object
– Equipment properties
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Last changed on The last change of the objects of this unit is specified with date and time.
Available The check box specifies that the unit can be allocated to batches. This is
a default setting.
Runtime name This consists of a prefix (symbolic computer name of the OS station) and
the path to the WinCC tag, separated by ::. Example: OS_KH1D331::Proc‐
ess cell/unit1/CFCChart/UnitBlockName
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 1015
