Specifically the batch objects are:
● Batch types:
– Data types
– Units of measure
– Operation types, phase types, and process tag types
– Equipment properties
● Batch instances:
– Process cell (folder)
– Units (folder)
– Equipment properties → currently selected object
– Equipment modules (EMOD) (folder)
– Neutral folder
– Equipment phases (EPH)
– Parameters of equipment phases
– Equipment operations (EOP)
– Parameters of equipment operations
– Process tags
– Process tag parameters
Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Setpoint Drop-down list for selecting a setpoint, e.g., for data type "Boolean" "True",
or "False".
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
1018 Operating Manual, 02/2016, A5E35958174-AA
