Runtime name in the dialog header
Display of the runtime name.
Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the navigation tree.
Description Any object description by the user.
Runtime name This consists of a prefix (symbolic computer name of the OS station) and
the path to the WinCC tag, separated by ::. Example: OS1_KH1D331::Proc‐
ess cell1/Unit1/CFC/EOPParameter
Name
Assigned phase type Type definition for process cell-neutral recipe creation.
Block Indicates the version of the phase type used.
Created by Specification of the application that created the object, either SIMATIC
BATCH PCell Control Center or SIMATIC Manager:
● If a type object was created by SIMATIC Manager, additional subobjects
cannot be added, nor can the selected object be deleted or changed,
either via the PCC API or with the PCC configuration dialog.
● If an instance object was created by SIMATIC Manager, additional
subobjects can be added via the PCC API or with the PCC configuration
dialog. However, it is still not possible to delete or change the selected
object here.
Function block
Buttons
Check validity All batch instances, starting with the selected object (an equipment phase,
in this case), are checked for consistency with batch types and for con‐
formity to ISA-88.
Update All batch instances are adapted according to the batch types. This action
is always required if a change has been made to batch types of existing
batch instances (e.g., inserting a new parameter, changing the unit of
measure, etc.).
Delete The EPH object can be deleted here. All subobjects (unit class parameters)
are implicitly deleted. Deletion is only possible if the selected object is not
in use.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 1027
