Block Indicates the version of the phase type used.
Created by Specification of the application that created the object, either SIMATIC BATCH
PCell Control Center or SIMATIC Manager.
● If a type object was created by SIMATIC Manager, additional subobjects
cannot be added, nor can the selected object be deleted or changed, either
via the PCC API or with the PCC configuration dialog.
● If an instance object was created by SIMATIC Manager, additional subobjects
can be added via the PCC API or with the PCC configuration dialog. However,
it is still not possible to delete or change the selected object here.
Function block
Buttons
Check validity All batch instances, starting with the selected object (an equipment opera‐
tion, in this case), are checked for consistency with batch types and for
conformity to ISA-88.
Update All batch instances are adapted according to the batch types. This action
is always required if a change has been made to batch types of existing
batch instances (e.g., inserting a new parameter, changing the unit of
measure, etc.).
Delete The selected object, including its subobjects, is deleted.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Display of possible additional functions.
OK button
Saves your settings and closes the dialog.
Cancel button
Closes the dialog without saving changes.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 1033
