The status of the assignments found are displayed as follows:
● A box with a check indicates that the element should be imported.
● Empty boxes mean that the element will not be imported. If you do not import an element,
the imported recipe, library is not valid.
Making assignments
● The Import Assistant checks if specific elements are already in the target process cell. If
any are, the Import Assistant suggests using these elements by automatically creating an
assignment.
● If you wish to change/create an assignment, mark the line with the element for which you
want to make an assignment and double-click on the corresponding element right in the
window listing those elements that are not yet assigned. Alternatively you can also activate
the left arrow instead of double click.
● If you do not want to use an allocation you can ether remove it via the shortcut menu or
remove it with the right arrow.
Result
The system checks if all elements with a check mark have an assignment. If they do not, correct
this and press "Next" again.
Parameters
This column contains the objects to be imported (e.g., parameters). The check box indicates
whether you want to import the element. If you do not import a parameter, the imported recipe
or library will become invalid.
Status displays
Symbol Meaning
There is a conflict that must be resolved.
Data are imported under a new name.
Data are replaced by data from the target process cell.
Data are imported unchanged.
Data have been deselected for the import.
Assigned
The assigned element is displayed here.
Note
This is where information on the status of the object is specified.
Context help references
14.2 BCC menu commands
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 1087
