Functions available for BATCH configuration
Object Meaning Available functions
BATCH client
application
● Configuring the BATCH clients
(Page 127)
BATCH con‐
trol server or
data storage
system
● Configuring the BATCH server
(Page 126)
Only in a re‐
dundant sys‐
tem:
BATCH con‐
trol server or
data storage
system stand‐
by
● Configuration of the redundant BATCH
server (Page 60)
WinCC appli‐
cation on
PCS 7 OS
● Compiling the OS (Page 176)
BATCH application client
"BATCH application client" stands for the BATCH Recipe Editor, the Batch Control Center
(BatchCC) for batch operation and observation, and batch data management.
BATCH application
"BATCH application" is the representative for
● DB server project: Storage of user permissions
● DB server offline: Storage of the recipes, formulas, materials
● DB server online: Storage of the batches
● BATCH control server (BCS)
BATCH application [stdby]
"BATCH application [stdby]" stands for the redundant applications:
● DB server project: Storage of user permissions
● DB server offline: Storage of the recipes, formulas, materials
● DB server online: Storage of the batches
● BATCH control server (BCS)
Engineering
7.1 Basic engineering for PCS 7
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 125
