strategy name. During parameter assignment in the recipe, only the parameters belonging to
the control strategy are available.
Note
Only one control strategy parameter can be created per operation/phase type.
Placing BATCH blocks in the plant hierarchy
The BATCH interface blocks as well as the BATCH type blocks are stored within the CFC
charts according to their function in the appropriate hierarchy folders, in the plant view in the
SIMATIC Manager.
Blocks of the BATCH block library
The names of the following BATCH blocks must not be modified:
● UNIT_PLC
● EventSend
● MemIDB64
The BATCH configuration dialog searches the S7 project for the block names listed above in
order to be able to make internal project settings. If the names are changed, SIMATIC BATCH
cannot be configured correctly.
In CFC charts, only blocks from the "BATCH" block family in the SIMATIC BATCH library may
be used and, therefore, imported. If necessary, blocks from the "Runtime" block family in the
SIMATIC BATCH library are automatically imported to the "Blocks" folder (offline block folder),
but must not be used in the CFC charts.
Note
All SIMATIC BATCH blocks of version BATCHflexible V4 are fully functional in this version but
can no longer be changed during engineering. The "IUNIT" and "UNIT_BLOCK" blocks from
block library versions before SIMATIC BATCH V7.1 SP2 are also fully functional but can no
longer be changed.
See also
Setting up the equipment module with SFC types (Page 155)
Engineering
7.1 Basic engineering for PCS 7
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 145
