Project data from the PCS 7 basic engineering is collected in the form of objects in a structure
in the navigation area for SIMATIC BATCH. When you select an object in the navigation area,
its properties are then displayed and special context-dependent functions are offered.
Note
All actions in the BATCH configuration dialog must be made in the same PCS 7 project
exclusively from one PC.
Following the creation of Batch objects (units and equipment modules) in basic engineering,
the name of your batch process cell must not be changed, neither in SIMATIC Manager within
the plant view nor in the BATCH configuration dialog in the process cell settings.
Following the actions "Retrieve", "Save as", "Save as with reorganization" and "Reorganize"
in SIMATIC Manager, you must generate the BATCH types and compile/merge the BATCH
instances in the BATCH configuration dialog prior to distributing the batch data.
Engineering
7.3 BATCH engineering
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 179
