● The print settings from the BCC are not used for printing and the print preview. For printing
and the print preview, the print settings of the IE apply.
● The print settings apply to all IE instances regardless of whether the print settings are made
in the shortcut menu of the IE in the preview or directly via the shortcut menu of the IEE.
The following also applies:
● You perform the action of printing both directly in the dialog and via the shortcut menu.
● In contrast, you run the print preview only via the shortcut menu.
● If the BCC is started from WinCC the "Preview" tab is not displayed in the "Updating the
process cell" dialog.
Effects on the status of the recipes and formulas
After updating the process cell, all the recipes (master recipes, library operations) of this
process cell that were "released for production" and "released for testing" are changed to the
"Testing release" status. Objects in the "Testing release" status are checked automatically. If
the check is successful, the objects are returned to their original status. If the check is
unsuccessful, the objects are changed to the "Release invalid" status. Depending on the
project settings, they can now be edited and they can be released again.
In the overview lists (Page 259) you can, for example, release the recipes with one action by
selecting several rows and the command "Release for production" (shortcut menu).
Batch status changes with "Updating the process cell"
Batches with the status "blocked" and "released" are automatically checked when the process
cell is updated. They are set to the status "Testing release" for this.
During a process cell update, first the batch status is checked. The result of the check
distinguishes between incorrect and correct batches.
Batch status before the check Result of the check Batch status after the check
Released Batch is OK Released
Blocked Batch is OK Blocked
Released Batch is defective Release invalid
Blocked Batch is defective Release invalid
If a batch has "Release invalid" status following the check, you can no longer use this batch.
You can only delete it.
Additional information
"Assignment" tab in the "Updating the process cell" dialog (Page 800)
"Preview" tab in the "Updating the process cell" dialog (Page 804)
Updating a BATCH process cell (Page 292)
BATCH Control Center
9.3 Reading in the ES data
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 291
