Changes:
1. The name of the "ROP" has been changed to "Recipe operation".
2. The "Heat_1" recipe step has been deleted.
3. The "Trans_2" transition has been deleted.
4. The "Agitate_4" recipe step has been added.
5. The "Trans_5" transition has been added.
Conditions for comparison of the two master recipes V1.0 and V2.0
● For the following comparison result, master recipe V1.0 was selected first and then master
recipe V2.0. For this reason, the values of recipe V1.0 are located in the left column of the
result and the values of recipe V2.0 are located in the right column.
● Only data needed to explain the principle, and not the entire data, is shown.
● In addition, the result elements are shown in expanded state, like in the printout.
Result of the comparison, display and interpretation
The individual attributes are shown in the following result blocks. The display is influenced by
your filter selection from the toolbar. The result window contains:
● All elements in the right and left columns that have not changed and/or
● All elements in the right and left columns that have changed and/or
● The elements in the right column that are only present in the comparison object of the right
column
● The elements in the left column that are only present in the comparison object of the left
column
Property Value (left side) Value (right side)
Recipe_example_1
<absolute path>
Recipe
Name Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58
(UTC +2:00)
01.06.2015 11:06:05 (UTC
+2:00)
<Additional attributes> … …
RUP_1
<Absolute path>
Recipe unit procedure
Name RUP RUP
<Additional attributes> … …
Recipe_operation_2
<Absolute path>
Recipe operation
Name ROP Recipe operation
<Additional attributes> … …
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 331
