Siemens SIMATIC BATCH User Manual

Property Value (left side) Value (right side)
Lib_reference_Test_25
<Absolute path>
Library reference
Comment
Library reference LibReferenceTest
Description
Planned run time 00 S
Monitoring time 00 S
Scaling the runtime
Overwrite runtime No
ESIG activated No
A library reference in the flat recipe has been resolved.
The "Resolve substructure" command also applies to library references in flat recipes. The
library reference is shown as deleted, and a substructure with the name of the previous library
reference is shown as added.
Property Value (left side) Value (right side)
Recipe_example_1
<absolute path>
Recipe
Recipe Recipe example Recipe example
Version V1.0 V2.0
Last change 08.06.2015 14:36:58
(UTC +2:00)
01.06.2015 11:06:05
(UTC +2:00)
<Additional attributes> … …
Lib_reference_Test_6
<absolute path>
Library element
Comment
Name LibReferenceTest
Description
Planned run time 00 S
Monitoring time 00 S
Overwrite runtime No
Scaling the runtime
ESIG activated No
LibReferenceTest
<Absolute path>
Library reference
Comment
Library reference LibReferenceTest1
Description
Planned run time 00 S
Monitoring time 00 S
Scaling runtime
Overwrite runtime No
ESIG activated No
BATCH Control Center
9.5 Recipes
SIMATIC BATCH V8.2
344 Operating Manual, 02/2016, A5E35958174-AA
