Symbol Status Meaning Planning list Status list Results list
Pausing after step The batch was paused, the steps cur‐
rently being executed are completed.
X
paused after step The batch was paused, the steps cur‐
rently being executed are completed.
X
Held The batch was held. X
Aborted The batch was aborted by operator in‐
tervention. Processing can no longer
be resumed.
X
Stopped The Batch was stopped due to an op‐
eration. Resumption is no longer pos‐
sible
X
Completed The batch was completed correctly. X
Testing release After updating the process cell data,
released batches change to the "test‐
ing release" status.
After the update, the batches in the
"testing release" status are checked
automatically. If the check is success‐
ful, the batches are returned to their
original status. If the testing is unsuc‐
cessful the elements will be transfer‐
red to the status "Release invalid".
Such batches must no longer be used
and can only be deleted!
X X
Release invalid X X
Additional status
The following symbols indicate other batch statuses in addition to those listed above. These
symbols are superimposed on the type symbol for orders.
Symbol Status Meaning Planning list Batch status list Results list
Chained The batch is chained with a
predecessor.
X X
Closed The batch is closed and can
be archived.
X X
Archived The batch is archived. The
batch can now be deleted.
X X
Error At least one recipe phase in
the control recipe of the
batch has reported an error
or the batch control itself is
in an exceptional state.
X X
BATCH Control Center
9.6 Batch Planning
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 373
