Automatic complete obsolete
If you have selected the setting "Yes" for "Extended continuous mode" under batches in the
project settings, automatic complete by means of SIMATIC BATCH in hierarchical recipes at
the end of an RUP or with flat recipes at the end of the batch becomes obsolete.
If you still want automatic complete to continue, integrate a non-continuous recipe phase
(continue not activated) within the existing master recipe:
● For hierarchical recipes at the end of an RUP
● For flat recipes at the end of a batch
BATCH Control Center
9.8 Batch control
SIMATIC BATCH V8.2
406 Operating Manual, 02/2016, A5E35958174-AA
