Objects Data contents Name part
ID
Complete name
of the standard
report templates
in the database
Recipes The master recipe report contains all the data re‐
quired for the production of your product. These in‐
clude:
● Recipe header data
● Input material and output material lists
● Procedural rules
● Visual representation of the master recipe with
processing history and all recipe elements used
_recipe standard_recipe.rdl
Batches The batch report contains all the information required
for the reproducibility of the batch process, quality as‐
surance and the fulfillment of legal requirements.
These include:
● Identification data
● Control recipe data
● Effective production data
● Timeline of recipe steps
● Error and alarm messages
● Operator interventions
_batch standard_batch.rdl
Toolbar in the report window
There is a toolbar in the top left corner of the print preview window where the batch report is
displayed. The function symbols displayed in the toolbar help you to navigate in the preview
and to export the report to a PDF file.
You can use your mouse and keyboard for additional navigation options within the report:
● With the mouse scroll wheel: Scroll up and down within a page of the report
● Press and hold SHIFT while using the mouse scroll wheel: Scroll page by page (shifting of
screen contents)
● Press and hold Ctrl while using the mouse scroll wheel: Zoom function
Export
You export the displayed report with the "Export" function in the print preview window.
The settings for exporting the report are made in the BatchCC by selecting Options > Settings
> Project Settings > "Report creation" folder under "Default directory for PDF files". If you check
the "Name and directory of PDF file can be changed" box, you have to enter a name and
BATCH Control Center
9.9 Report creation and archiving of batch data
SIMATIC BATCH V8.2
478 Operating Manual, 02/2016, A5E35958174-AA
