Opening objects
There are several ways of opening an object:
● Double-click on the object icon.
● Select the object and then the menu command Edit > Open object.
After opening an object, you can create or modify its content.
Properties of objects
Object properties are data belonging to the object that decide its behavior,
for example the properties of a recipe operation.
The menu command Edit > Properties opens a dialog box in which you can see and set the
properties of the selected object.
Cut, Paste or Copy
As is usual under Windows, you can: cut, paste or copy most objects. You will find the
respective menu commands in the "Edit" menu.
You can also copy objects using (Drag-and-drop). If you point to an illegal target, the cursor
changes to a forbidden sign.
When you copy an object, the entire hierarchy below it is also copied. As a result you have
wide options open to you if you want to use your developed components more than once.
Note
When you insert, the target position must be specified by mouse click.
Renaming objects
You can change the name of an object at a later point in time in the object properties.
Deleting objects
You can delete all objects. Deleting can be undone. A master recipe or a library operation can
only be deleted in BatchCC.
Undoing/redoing actions
With the Undo/Redo menu commands, you can reverse modifications step-by-step.
After undoing "n" actions, you can also redo "n" actions.
BATCH Recipe Editor
10.2 Starting and operating
SIMATIC BATCH V8.2
498 Operating Manual, 02/2016, A5E35958174-AA
