Example with invalid limits (limits in the recipe header are too wide)
The master recipe is intended for quantities of 2 to 15. With these limit values, there are no
valid values for the parameters of the recipe phases:
Scaling: Linear
Low limit Parameter/reference quan‐
tity
High limit
Instance parameter 3 20
Recipe header 2 10 15
Parameter 15 13 13.33333333
Quantity of the batch 15
Online 19.5
Scaling: quadratic
Low limit Parameter/reference quan‐
tity
High limit
Instance parameter 3 20
Recipe header 2 10 15
Parameter 75 13 8.88888889
Quantity of the batch 12
Online 18.72
Example with valid limits (recipe limits corrected)
The range was restricted in the recipe header. The value 13 can be used.
Scaling: Linear
Low limit Parameter/reference quan‐
tity
High limit
Instance parameter 3 20
Recipe header 3 10 15
Parameter 10 13 13.33333333
Quantity of the batch 15
Online 19.5
Scaling: quadratic
Low limit Parameter/reference quan‐
tity
High limit
Instance parameter 3 20
Recipe header 5 10 10
Parameter 12 13 20
BATCH Recipe Editor
10.4 Creating recipes
SIMATIC BATCH V8.2
580 Operating Manual, 02/2016, A5E35958174-AA
