Template with all SIMATIC BATCH OS controls
All available BATCH OS controls are provided in a template. You can find the template under
the name "@simatic_batchos.pdl" in the WinCC project folder "wincproj\computer_name
\GraCS".
If you configure the OS controls in your own process pictures, note that your process picture
must always contain the following OS controls:
● OS control "Master": necessary because it is used to establish a connection to the BATCH
project.
● OS control "Monitor": necessary because it is used to display and acknowledge operator
input dialogs and confirmation dialogs.
● OS control "Batch Creation": only necessary if batches are generated. Not necessary if
batches are being monitored in a process picture.
Check boxes for the OS controls "Process Cell", "Properties", "Allocation", and "Creation"
For the OS controls, there are check boxes for the following settings in the template screen:
Check boxes in the OS control "Process Cell" Meaning
Show tree structure The tree structure in the navigation area is displayed or
hidden by selecting or clearing the check box. You use
the tree structure to navigate within a batch. When
cleared, the list view is displayed in the left area of the
OS Control.
Batch scheduling mode When selected, some table columns that are not nec‐
essary for scheduling are hidden. This makes the dis‐
play easier to view in process mode.
Check boxes in the OS control "Properties" Meaning
Show tree structure The tree structure in the navigation area is displayed or
hidden by selecting or clearing the check box. You use
the tree structure to navigate within a batch. When
cleared, the used control recipe is displayed in the left
area of the OS Control.
Extended parameter display Some table columns are displayed or hidden by select‐
ing or clearing the check box.
Check boxes in the OS control "Allocation" Meaning
Advanced view Some table columns are displayed or hidden by select‐
ing or clearing the check box.
Check boxes in the OS control "Creation" Meaning
Extended batch generation Some fields that are not necessarily required for batch
creation are displayed or hidden by selecting or clearing
the check box.
You can select or clear check boxes in both the undocked status and the embedded status.
BATCH OS controls
11.1 Introduction
SIMATIC BATCH V8.2
586 Operating Manual, 02/2016, A5E35958174-AA
