Bit Hex value Meaning Bit Hex value Meaning
9 0x0000 0200 STARTING, ISA-88
state
25 0x0200 0000 Reserved
10 0x0000 0400 RESUMING,
ISA-88 state
26 0x0400 0000 Reserved
11 0x0000 0800 COMPLETING,
ISA-88 state
27 0x0800 0000 Reserved
12 0x0000 1000 HOLDING, ISA-88
state
28 0x1000 0000 Reserved
13 0x0000 2000 ABORTING,
ISA-88 state
29 0x2000 0000 Reserved
14 0x0000 4000 STOPPING,
ISA-88 state
30 0x4000 0000 Reserved
15 0x0000 8000 Not used 31 0x8000 0000 General error
Note
The BA_STAT status word can contain an ISA 88 status and other operating modes (for
example automatic or manual). It is not possible for more than one ISA -88 status to be present
at the same time. The continuous mode may only be set in the ready to complete status.
Recommended procedure
12.5 How are IEPH/IEOP blocks connected to the user blocks?
SIMATIC BATCH V8.2
684 Operating Manual, 02/2016, A5E35958174-AA
