When a single master recipe is open in the Recipe Editor, you can also search for the process
cell reference object.
The search for these elements can be used in recipe steps, transitions, container objects (RUP/
ROP/SUB) in the recipe header or libraries.
The dialog is accessed via the menu command "Find" in the "Edit" menu, or via the
corresponding menu command from the shortcut menu. When the master recipe/library is
selected or open, you can also use the keyboard shortcut "Ctrl+F". You can search
simultaneously in multiple objects with multiple selection in a detail view.
Image 14-8 "Find" dialog
Dialog description
The dialog is divided into various sections.
In the upper section, "Find what", you can specify your search. You search for text, data types,
and structures. Other fields are offered depending on your selection. For a text search, enter
a keyword in the text box and click "Start". All printable characters, including text sections, can
be used as search terms in any length. Wildcards cannot be used. The text search only finds
elements that you can select or enter during the creation of recipes. For example, no comments
on blocks or units from PCS 7 engineering are included in the search. Parameter names are
searched. Additional criteria are available for the "Data types" and "Structures" selection,
allowing you to fine tune your search.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
848 Operating Manual, 02/2016, A5E35958174-AA
