Stations
Button Function
Update The basic data of the BATCH process cell is generated or updated..
For AS-based operation, the configuration from basic engineering is adapted
as follows:
● The necessary CFC charts are created or updated for AS-based operation.
Example: @ASB_Mem.
● The BATCH application or standby BATCH application in your SIMATIC
PC station is / are replaced.
● Missing S7 connections between the Batch application and the AS are
created.
Note
S7 connections are created for H-CPUs. You have to configure fault-
tolerant connections in Netpro yourself. They are then used by SIMATIC
BATCH.
Compile / Download Opens the "Compile / Download" dialog. The dialog consists of various tabs in
which you compile/download blocks (data and memory blocks), charts or pro‐
grams.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Stations" to show all station errors or warnings. You can also
right-click a selected object and select the "Display log" function to
display object-specific errors or warnings.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
864 Operating Manual, 02/2016, A5E35958174-AA
