Process cell data
For navigation in the process cell data.
Properties
Name of the object selected in the process cell tree.
Description You describe your batch types in this text box.
Last changed on The most recent change of the batch types are specified with date and time.
Batch types
Buttons
Propagate Use this button to open the "Propagate types total process cell" dialog.
Generate Use this button to open the "Generate types" total process cell" dialog.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file with the specified layout and dis‐
played in the Internet Explorer.
With the "Batch types" selection all errors or warnings of the batch
types are always displayed. In a selected object you can also right click
to select the "Show Log" function to also show object-specific errors
or warnings.
Additional functions
Print This prints all batch types of the process cell in tabular form.
OK button
Saves your settings and ends the dialog.
Apply button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
870 Operating Manual, 02/2016, A5E35958174-AA
