Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Operation types
Button Description
New Click "New" to add a new operation type from version 5/6i.
Log
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The logging function is activated with the "Display" button. The selec‐
ted log is generated as an XML file in the specified layout and shown
in Internet Explorer.
Select "Process cell" and click on the "Display" button to show all proc‐
ess cell errors or warnings. Moreover on a selected object you can
right click to select the "Display Log" dialog to also show object-specific
errors or warnings.
Additional functions
Display of possible additional functions.
"OK" button
Saves your settings and ends the dialog.
Accept button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
"Cancel" button
Closes the dialog without saving changes.
"Help" button
Opens the SIMATIC BATCH online help for this context.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
880 Operating Manual, 02/2016, A5E35958174-AA
