"Control strategy parameter"
check box
If this check box is selected, you can make the control strategy settings
for this type at the type parameter.
This option is only available after at least one control strategy type has
been configured under data types.
Events log ID: Here, you can specify a value from 0 to 65535 that can be evaluated
later in a user batch report to allow filtering. Different values are permit‐
ted for setpoint and process value. This means, for example, that you
could filter according to setpoints with setpoint ID < 1000 AND setpoint
ID ≥ 500 and according to process values with process value ID ≤ 2000.
The user can specify how convenient such a query is in his log software.
Parameters
Button
Delete Click "Delete" to delete the selected phase type parameter.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Instances
"Display" button All instance parameters that refer to this unit of measure are listed in a
dialog box. Certain attributes can be selected by means of a special filter.
Or no instance exists.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 891
