Properties
Name of the object selected in the process cell tree.
Description The description of the interface block is displayed In this text field. Descrip‐
tion texts are entered in the object properties in the SIMATIC Manager.
Run time name Corresponds to the WinCC variable name plus the OS name as prefix.
CFC chart CFC chart name in which the block is located.
"Open" button
Not possible in the multi‐
project.
Click on the "Open" button to open the appropriate CFC chart and select
the block.
"Parameters" button Clicking this button takes you to the corresponding process tag type pa‐
rameter. With the Back button of the process tag type parameter, you return
to this location.
Bloc
Button
Compile
This button only exists for
a project and not for a
multiproject.
All batch instance blocks of the CFC chart of the selected object are read
in. This also implicitly involves a check for consistency with the batch types
and conformity to ISA-88.
Log
Not possible in the multiproject
"Errors" display field The number of errors for the selected log are displayed.
"Warnings" display field The number of warnings for the selected log are displayed.
"Display" button The "Display" button activates the log. The selected log is generated
as an XML file with the specified layout and displayed in the Internet
Explorer.
The "Display" button is always shows all errors/warnings for the selec‐
ted "Process cell". Moreover on a selected object you can right click
to select the "Display Log" dialog to also show object-specific errors
or warnings.
Additional functions
Display of possible additional functions.
"OK" button
Saves your settings and ends the dialog.
"Apply" button
Your settings will be saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
908 Operating Manual, 02/2016, A5E35958174-AA
