necessary to establish name agreement between plant hierarchy process cell and batch
process cell over all projects of a multiproject.
Batch process cell name of the multiproject
In this input field you can assign a new name for your batch process cell. When exiting the
dialog with the "OK button all batch and plant hierarchy process cells will be renamed to this
name.
S88 process cells only
The check box is activated per default. Thus in the table below only plant hierarchy process
cells that have the ISA S88 type definition will be displayed.
Project
Name of the project.
Path
Display of the project path.
Batch process cell
Name of the Batch process cell.
Process cell
This table column is only displayed if the check box "S88 process cells only" is activated.
If the names are the same in the multiproject, this is a display field.
If the names are not the same in the multiproject, this is an input field. The names that deviate
from the names of the batch process cell are displayed with a red font. This means that you
must establish the same names. Either rename the names displayed in red uniformly, rename
all names displayed in black, or use a new name.
Note
If the names do not agree then all process cell names can only be renamed if all projects are
added in the multiproject.
PH folder
This table column is only displayed if the check box "S88 process cells only" is deactivated.
All 1st level hierarchy folders from the ES are displayed.
If a name conflict occurs when renaming a process cell (ISA-88 type definition), the name of
the respective PH folder can be changed here.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
948 Operating Manual, 02/2016, A5E35958174-AA
