"Update" check box
If you select the check box in the "Update" column header or below the individual object and
then click the "Start" button, the system recalculates and adjusts the number or memory blocks.
This means that changes in the basic engineering are adopted.
Name
Name of the folder containing the CFC/SFC charts and SFC types. Name of the S7 chart folder.
"Compile" check box
If you select the "Compile" check box in the column header or below the individual object and
then click the "Start" button, the "Compile program" dialog is displayed. Here you can set the
scope for compiling the charts as a program. If you then click the "OK" button, the compilation
is started according to your settings. At the end of the compilation, the relevant log is displayed.
The symbols for the "Compile" and "Download" functions are as follows:
Symbol Meaning
The object must be compiled/downloaded
The object was not compiled/downloaded. Check the log for the action. Click the button in
the "Log" column and repeat the action.
The object was successfully compiled/downloaded, however with warnings. Click the "Log"
button to view the warnings.
The object was successfully compiled/downloaded.
Operating mode
The availability of the AS is checked.
"Download" check box
If you select the "Download" check box in the column header or below the individual object
and then click the "Start" button, the "Download S7" dialog is displayed. Here, you can set the
download mode. If you then click the "OK" button, the download to the AS is made. At the end
of the download, the relevant log is displayed.
"Log" button
Each object listed in the table corresponds to an S7 chart folder of a project. For each object
row, there are two buttons in the "Log" column. If you click the left button, the BATCH validation
of the stations is displayed. If you click the right button, the result logs of compiling and
downloading the S7 program will be displayed.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
950 Operating Manual, 02/2016, A5E35958174-AA
