Block Drop-down list for selection of the following block types:
● IEOP / EOP SFC type: Phase type based on interface block and SFC
type.
● IEOP: Phase type based on interface block.
● EOP SFC type: Phase type based on SFC type.
Created by Specification of the application that created the object, either SIMATIC
BATCH PCell Control Center or SIMATIC Manager.
● If a type object was created by SIMATIC Manager, additional subobjects
cannot be added, nor can the selected object be deleted or changed,
either via the PCC API or with the PCC configuration dialog.
● If an instance object was created by SIMATIC Manager, additional
subobjects can be added via the PCC API or with the PCC configuration
dialog. However, it is still not possible to delete or change the selected
object here.
Phase type
Buttons
Update All batch instances are adapted according to the batch types. This action is always
required if a change has been made to batch types of existing batch instances
(e.g., inserting a new parameter, changing the unit of measure, etc.).
New A new "Phase type parameters" subobject is created below the selected "Phase
type" object.
Delete The phase type object can be deleted here. All subobjects (phase type parame‐
ters) are implicitly deleted. Deletion is only possible if the selected object is not in
use.
Log
"Errors" display field The number of errors for the selected log is displayed.
"Warnings" display field The number of warnings for the selected log is displayed.
"Display" button The logging is activated with the "Display" button. The selected log is
generated as an XML file in the specified layout and displayed in In‐
ternet Explorer.
Select "Process cell" and click the "Display" button to show all process
cell errors or warnings. You can also right-click a selected object and
select the "Display log" function to display object-specific errors or
warnings.
Additional functions
Displays: All instances that refer to this phase type are listed in a dialog box. Certain attributes
can be selected by means of a special filter.
OK button
Saves your settings and closes the dialog.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
990 Operating Manual, 02/2016, A5E35958174-AA
