5. PARAMETERS
5 - 48
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
Control
mode
P
S
T
PC36
*DMD
Status
display
selection
_ _ x x
Status display selection at power-on
Select a status display shown at power-on. Setting "21" to "27" will trigger [AL. 37] in
the mode other than the positioning mode.
00: Cumulative feedback pulses
01: Servo motor speed
02: Droop pulses
03: Cumulative command pulses
04: Command pulse frequency
05: Analog speed command voltage (Note 1)
06: Analog torque command voltage (Note 2)
07: Regenerative load ratio
08: Effective load ratio
09: Peak load ratio
0A: Instantaneous torque/thrust
0B: Within one-revolution position/within virtual one-revolution position (1 pulse unit)
0C: Within one-revolution position/within virtual one-revolution position (1000 pulses
unit)
0D: ABS counter/virtual ABS counter
0E: Load to motor inertia ratio/load to motor mass ratio
0F: Bus voltage
10: Internal temperature of encoder
11: Settling time
12: Oscillation detection frequency
13: Number of tough operations
14: Unit power consumption (increment of 1 W)
15: Unit power consumption (increment of 1 kW)
16: Unit total power consumption (increment of 1 Wh)
17: Unit total power consumption (increment of 100 kWh)
18: Load-side cumulative feedback pulses
19: Load-side droop pulses
1A: Load-side encoder information 1 (1 pulse unit)
1B: Load-side encoder information 1 (100000 pulses unit)
1C: Load-side encoder ABS counter
1D: Z-phase counter (1 pulse unit)
1E: Z-phase counter (100000 pulses unit)
1F: Electrical angle (1 pulse unit)
20: Electrical angle (100000 pulses unit)
00h
Note 1.
It is for the speed control mode. It will be the analog speed limit voltage in
the torque control mode.
2.
It is for the torque control mode. It will be the analog torque limit voltage in
the speed control mode and position control mode.
_ x _ _
Status display at power-on in corresponding control mode
0: Depends on the control mode
0h
Control mode
Status display at power-on
Position
Cumulative feedback pulses
Position/speed
Cumulative feedback pulses/servo motor speed
Speed
Servo motor speed
Speed/torque
Servo motor speed /analog torque command
voltage
Torque
Analog torque command voltage
Torque/position
Analog torque command voltage/cumulative
feedback pulses
1: Depends on the last 2 digits settings of the parameter
x _ _ _
For manufacturer setting
0h
