16. POSITIONING MODE
Device
Symbol
Connector
pin No.
Function and application
I/O
division
Control
mode
CP
CL
PS
Program output
1
OUT1
OUT1 will turn on with the OUTON (1) command during programming.
The OUTOF (1) command will turn off OUT1.
You can also set time to off with [Pr. PT23].
DO-
1
Program output
2
OUT2
OUT2 will turn on with the OUTON (2) command during programming.
The OUTOF (2) command will turn off OUT2.
You can also set time to off with [Pr. PT24].
DO-
1
Program output
3
OUT3
OUT3 will turn on with the OUTON (3) command during programming.
The OUTOF (3) command will turn off OUT3.
You can also set time to off with [Pr. PT25].
DO-
1
Point table No.
output 1
PT0
The signals output point table Nos. in 8 bit code simultaneously with MEND
(Travel completion) on.
DO-
1
Point table No.
output 2
PT1
Device (Note 1, 2)
Description
PT7
PT6
PT5
PT4
PT3
PT2
PT1
PT0
Point table No.
output 3
PT2
0
0
0
0
0
0
0
1
Point table No. 1
Point table No.
output 4
PT3
0
0
0
0
0
0
1
0
Point table No. 2
Point table No.
output 5
PT4
0
0
0
0
0
0
1
1
Point table No. 3
Point table No.
output 6
PT5
Point table No.
output 7
PT6
1
1
1
1
1
1
1
0
Point table No. 254
Point table No.
output 8
PT7
1
1
1
1
1
1
1
1
Point table No. 255
Note 1.
0: Off
1: On
Station output 1
PS0
The signals output station Nos. simultaneously with MEND on while an
alarm is not occurring.
DO-
1
Station output 2
PS1
Device (Note 1, 2)
Description
PS7
PS6
PS5
PS4
PS3
PS2
PS1
PS0
Station output 3
PS2
0
0
0
0
0
0
0
0
In-position out of
range
Station output 4
PS3
1
1
1
1
1
1
1
1
Next station No. 0
Station output 5
PS4
1
1
1
1
1
1
1
0
Next station No. 1
Station output 6
PS5
1
1
1
1
1
1
0
1
Next station No. 2
Station output 7
PS6
1
1
1
1
1
1
0
0
Next station No. 3
Station output 8
PS7
0
0
0
0
0
0
1
0
Next station No. 253
0
0
0
0
0
0
0
1
Next station No. 254
Note 1.
0: Off
1: On
