Status display data value and
processing information
Oscillation detection frequency
Number of tough drive operations
Unit total power consumption
Command remaining distance
Point table No./Program No./
Station position No.
Cam axis one cycle current value
Cam axis feed current value
Cam stroke amount in execution
Main axis one cycle current value
(8) Point table setting data (command [4] [0], [4] [5], [5] [0], [5] [4], [5] [8], [6] [0], [6] [4])
Reading position data of each point table
The decimal equivalent of the data No. value (hexadecimal) corresponds to the
point table No.
Reading M code of each point table
The decimal equivalent of the data No. value (hexadecimal) corresponds to the
point table No.
Reading speed data of each point table
The decimal equivalent of the data No. value (hexadecimal) corresponds to the
point table No.
Reading acceleration time constant of each point table
The decimal equivalent of the data No. value (hexadecimal) corresponds to the
point table No.
Reading deceleration time constant of each point table
The decimal equivalent of the data No. value (hexadecimal) corresponds to the
point table No.
Reading dwell of each point table
The decimal equivalent of the data No. value (hexadecimal) corresponds to the
point table No.
Reading auxiliary function of each point table
The decimal equivalent of the data No. value (hexadecimal) corresponds to the
point table No.
