17．Positioning mode (pushing operation)
Device name
sym
bol
Connecto
r
pin No.
Functions and uses
I/O
Clas
sific
atio
n
Control
mode
C
P
CL
P
S
Start signal
ST1
CN1-17
point table method
1.In case of absolute value command method
When ST1 is turned on during automatic operation, one operation is executed
based on the positioning data and pushing operation data set in the point table.
Positioning mode During the pushing operation of the point table method, the
pushing operation is continued until ON of ST1 is detected.
When ST1 is turned on during home return, home return starts at the same time.
If ST1 is turned on during JOG operation, the motor will rotate in the forward
direction while it is on. Forward rotation indicates the direction of address
increase.
If both ST1 and ST2 are turned on during JOG operation, the servo motor will
stop.
2.Increment value command method
When ST1 is turned on during automatic operation, one positioning operation is
performed in the forward direction based on the positioning data set in the point
table.
Pushing operation cannot be performed.
When ST1 is turned on during home return, home return starts at the same time.
If ST1 is turned on during JOG operation, the motor will rotate in the forward
direction while it is on. Forward rotation indicates the direction of address
increase.
If both ST1 and ST2 are turned on during JOG operation, the servo motor will
stop.
DI-1
○
Program method
Same specifications as standard.
○
Equal indexing method
Same specifications as standard.
○
Reverse rotation
start
ST2
CN1-18
point table method
Same specifications as standard.
This device is not used during the point table method pushing operation.
DI-1
○
Program method
Same specifications as standard.
○
Equal indexing method
Do not use this device.
