Series 2600B System SourceMeter® instrument Reference Manual Section 7: Introduction to TSP operation
2600BS-901-01 Rev. F/August 2021 7-5
Data queue
Use the data queue commands to:
• Share data between test scripts running in parallel
• Access data from a remote group or a local node on a TSP-Link
®
network at any time
The data queue in the Test Script Processor (TSP
®
) scripting engine is first-in, first-out (FIFO).
You can access data from the data queue even if a remote group or a node has overlapped
operations in process.
dataqueue.add() (on page 9-49)
dataqueue.CAPACITY (on page 9-50)
dataqueue.clear() (on page 9-50)
dataqueue.count (on page 9-51)
dataqueue.next() (on page 9-52)
Digital I/O
The 2604B, 2614B, and 2634B do not have digital input/output lines. The commands to control the
digital input/output lines are not available for these models.
The digital I/O port of the instrument can control external circuitry (such as a component handler for
binning operations).
The I/O port has 14 lines. Each line can be at TTL logic state 1 (high) or 0 (low). See the pinout
diagram in Digital I/O port (on page 4-38) for additional information.
There are commands to read and write to each individual bit, and commands to read and write to the
entire port.
digio.readbit() (on page 9-54)
digio.readport() (on page 9-55)
digio.trigger[N].assert() (on page 9-55)
digio.trigger[N].clear() (on page 9-56)
digio.trigger[N].EVENT_ID (on page 9-56)
digio.trigger[N].mode (on page 9-57)
digio.trigger[N].overrun (on page 9-58)
digio.trigger[N].pulsewidth (on page 9-59)
digio.trigger[N].release() (on page 9-59)
digio.trigger[N].reset() (on page 9-60)
digio.trigger[N].stimulus (on page 9-61)
digio.trigger[N].wait() (on page 9-62)
digio.writebit() (on page 9-63)
digio.writeport() (on page 9-64)
digio.writeprotect (on page 9-64)
