Tektronix KEITHLEY 2600B Series User Manual

Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-372 2600BS-901-01 Rev. F/August 2021
Trigger event IDs*
Event ID
Event description
trigger.generator[N].EVENT_ID
Occurs when the trigger.generator[N].assert()
function is executed
* Use the name of the trigger event ID to set the stimulus value rather than the numeric value. Using the name makes the
code compatible for future upgrades (for example, if the numeric values must change when enhancements are added to the
instrument).
Example
digio.trigger[3].mode = digio.TRIG_FALLING
digio.trigger[5].mode = digio.TRIG_FALLING
trigger.blender[1].orenable = true
trigger.blender[1].stimulus[1] = digio.trigger[3].EVENT_ID
trigger.blender[1].stimulus[2] = digio.trigger[5].EVENT_ID
Generate a trigger blender 1 event when a digital I/O trigger happens on line 3 or 5.
Also see
trigger.blender[N].reset() (on page 9-370)
trigger.blender[N].wait()
This function waits for a blender trigger event to occur.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
triggered = trigger.blender[N].wait(timeout)
triggered
Trigger detection indication for blender
N
The trigger blender (up to six) on which to wait
timeout
Maximum amount of time in seconds to wait for the trigger blender event
Details
This function waits for an event blender trigger event. If one or more trigger events were detected
since the last time trigger.blender[N].wait() or trigger.blender[N].clear() was
called, this function returns immediately.
After detecting a trigger with this function, the event detector automatically resets and rearms. This is
true regardless of the number of events detected.
Example
digio.trigger[3].mode = digio.TRIG_FALLING
digio.trigger[5].mode = digio.TRIG_FALLING
trigger.blender[1].orenable = true
trigger.blender[1].stimulus[1] = digio.trigger[3].EVENT_ID
trigger.blender[1].stimulus[2] = digio.trigger[5].EVENT_ID
print(trigger.blender[1].wait(3))
Generate a trigger blender 1 event when a digital I/O trigger happens either on line 3 or 5.
Wait three seconds while checking if trigger blender 1 event has occurred.
If the blender trigger event has happened, then true is output. If the trigger event has not happened, then
false is output after the timeout expires.
