Section 9: TSP command reference Series 2600B System SourceMeter® instrument Reference Manual
9-376 2600BS-901-01 Rev. F/August 2021
Also see
trigger.timer[N].clear() (on page 9-375)
trigger.timer[N].delay (on page 9-376)
trigger.timer[N].reset() (on page 9-379)
trigger.timer[N].delay
This attribute sets and reads the timer delay.
Instrument reset
Recall setup
Trigger timer N reset
Usage
interval = trigger.timer[N].delay
trigger.timer[N].delay = interval
Delay interval in seconds (0.5 µs to 100 ks)
Trigger timer number (1 to 8)
Details
Once the timer is enabled, each time the timer is triggered, it uses this delay period.
Assigning a value to this attribute is equivalent to:
trigger.timer[N].delaylist = {interval}
This creates a delay list of one value.
Reading this attribute returns the delay interval that is used the next time the timer is triggered.
Example
trigger.timer[1].delay = 50e-6
Set the trigger timer 1 to delay for 50 µs.
Also see
trigger.timer[N].reset() (on page 9-379)
