Series 2600B System SourceMeter® instrument Reference Manual Section 9: TSP command reference
2600BS-901-01 Rev. F/August 2021 9-263
smuX.trigger.IDLE_EVENT_ID
This constant contains the idle event number.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Constant
Yes
Usage
eventID = smuX.trigger.IDLE_EVENT_ID
eventID
The idle event number
X
Source-measure unit (SMU) channel (for example,
smua.trigger.IDLE_EVENT_ID applies to SMU channel A)
Details
Set the stimulus of any trigger object to the value of this constant to have the trigger object respond to
idle events from this SMU.
Example
trigger.timer[1].stimulus = smua.trigger.IDLE_EVENT_ID
Trigger timer 1 when the SMU returns to the idle layer.
Also see
Triggering (on page 4-1)
smuX.trigger.initiate()
This function initiates a sweep operation.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
smuX.trigger.initiate()
X
Source-measure unit (SMU) channel (for example, smua.trigger.initiate()
applies to SMU channel A)
Details
This function causes the SMU to clear the four trigger model event detectors and enter its trigger
model (moves the SMU from the idle state into the arm layer).
To perform source actions during the sweep, before calling this function, it is necessary to configure
and enable one of the following sweep source actions:
• smuX.trigger.source.linearY()
• smuX.trigger.source.listY()
• smuX.trigger.source.logY()
